Automatic Vicat Apparatus

In a vicat test a needle drops freely into a cement sample. A sensor with 0.1mm resolution measures the penetration depth, as the cement hardness an initial and final setting times is measured and recorded.

$ 0.00 AUD

Thank you! Your submission has been received!

Oops! Something went wrong while submitting the form.

Categories:

Cement Testing

All CMT Laboratory

GS9000 Multichannel GPR for 3D Utility Mapping and Structural Assessment

‍

Discuss Your Application

Collect high-density, georeferenced GPR data across wide areas and view the subsurface in 3D as you scan. Choose the GX2 array for SUE and utility mapping, or the GX1 array for structural, bridge and pavement investigations.

Book a GS9000 Demonstration

SUE & utility mapping

Structural & pavement assessment

Best suited to:

Subsurface utility engineering
Utility locating and mapping
Civil and survey contractors
Road and corridor investigations
Void and subsurface anomaly surveys

Best suited to:

Bridge-deck investigations
Concrete cover and moisture mapping
Pavement and asphalt-layer assessment
Reinforcement mapping
Structural deterioration surveys

Recommended array: GX2

Recommended array: GX1

‍

Why use the GS9000 instead of a conventional single-channel GPR?

Cover more ground

Collect multiple parallel profiles in one pass instead of uilding a grid line by line.

See results during acquisition

View georeferenced radargrams and time-slice information in the field rather than waiting until the data is returned to the office.

Produce repeatable mapped data

Combine wheel-positioned GPR data with GNSS, project coordinates and survey linework.

Use one platform for two very different applications

Exchange GX1 and GX2 arrays without purchasing two complete cart platforms.

‍

High-density 3D GPR mapping for SUE and utility investigations

The GX2 transforms the GS9000 into a high-density subsurface utility mapping system. Its 11-channel, low-frequency GPR array captures an 83 cm-wide swath in each pass, helping operators detect and map buried pipes, ducts, cables, voids and other subsurface features. Live georeferenced data lets SUE teams review coverage on site and produce accurate CAD, GIS and project-coordinate deliverables.

Utility corridor mapping
Detection of pipes, ducts and cables
Mapping non-conductive services that may not respond to electromagnetic locating
Congested service investigations
Road-crossing and easement surveys
Potential void and cavity investigation
Pre-excavation and design-stage surveys
Utility mapping to project or local coordinates

‍

The SUE field workflow

‍

1. Plan the survey

Load satellite imagery, CAD information, project coordinates or survey control.

2. Collect dense multichannel data

Survey an approximately 0.82 m-wide swath with 11 channels in each pass.

3. Review data live

Examine radargrams, georeferenced time slices and marked features while still on site.

4. Interpret and digitise

Add points, linework, tags, photographs and field observations.

5. Process and deliver

Merge survey areas, apply processing and export mapped information for the customer’s CAD, GIS or reporting workflow.

‍

SUE Outputs and Deliverables

Technical Specification

Conforming to EN 196-3, 13279-2, 480-2, ASTM C191, C187
Large size 4,3" touch screen colour display
LAN port for direct connection to PC of a single unit or connection to a LAN hub for creating a network with up to 32 independent units all controlled by a single PC. 1 LAN cable is included
USB port for data storage on pen-drive (included)
Test procedures can be customized and stored to match user-defined requirements
Can incorporate an integrated graphic printer showing test result and setting time plot
Large test space with easy accessibility
Automatic calculation of initial and final setting time at programmable penetration depth limits
Wide range of accessories including EN and ASTM/AASHTO parts, in-water testing kit, needle cleaning device, integrated printer, probes for testing consistency and gypsum
Minimum penetrations rate: 10 seconds
Penetration measurement by encoder

No Items Found

Setting Time

Main Features

Functional and ergonomic design based on the innovative CVi-TECH philosophy.
Advanced electronics technologies providing superior performances and total flexibility combined with simplicity in use
Easy-to-use double interface: local mode, with large size 4,3" touch screen colour display and remote mode with PC
Supplied complete with PC software for data processing VICASOFT-BASIC
With PC software VICASOFT-PREMIUM (optional) up to 32 independent units can be connected to a single PC via LAN port and hub. All units are remotely controlled. Adopting the multi-test network concept laboratory productivity is maximized
Integrated graphic printer is available as optional accessory showing both results in numerical format and setting time plot
Easy setting and storage of user-defined test profiles allowing quick test start
Large accessibility to the test space
Practical in-water testing accessory (optional)
Automatic determination of initial and final setting time

Firmware Specifications

Easy programming of customized test profiles, recallable for future tests, including:
- adjustable test start delay
- penetration points positions
- manual or automatic penetration rate
- free or driven dropping mode
- holding intervals inside the sample
- automatic end- test detection
- automatic measurement of initial and final setting time

Test data: test number, operator, client, date, hour, cement type, water percentage, delay
Easy calibration menu
Clock calendar
Multi-language

Accessories

UTCM-0551 Accessory for Needle Continuous Cleaning and In-Water Testing

UTCM-0552 LAN hub for PC connection of up to 7 VICAMATIC- 2 units or up to 6 units in case of multi-hub network. LAN cable from hub to PC is included. Each VICAMATIC-2 unit is supplied complete with LAN cable.

UTCM-0553 Upgrading of a VICAMATIC-2 unit for incorporating a graphic printer into the head. Test settings and results are plotted both as numerical and graphical format including penetration depth/time diagram. The upgrading shall be factory installed.

UTCM-0554 Needle for Final Setting Test EN UTCM-0555 Cylindrical Probe for Consistency Test UTCM-0556 Additional Weight 700 g, UTCM-0557 Water thermostatic unit for VICAMATIC -2. Up to 2 units may be connected. 230 V, 50-60 Hz, 1 ph UTCM-0048/07/110 Water thermostatic unit for VICAMATIC -2. Up to 2 units may be connected. 110 V, 60 Hz, 1 ph UTCM-0558 Conical penetration probe 8 mm dia x 50 mm complete with 100g calibrated weight for gypsum testing to EN 13279

UTCM-0559 VICASOFT-PREMIUM Software for PC connection of up to 32 VICAMATIC-2 units including remote control of each unit, data acquisition - processing - filing, printout of test reports.

Communication via LAN port (each VICAMATIC-2 unit is supplied complete with LAN cable). The connection of one VICAMATIC-2 unit is direct via the PC LAN-port, for more VICAMATIC-2 units (up to 32) one or more LAN hubs are required with total number of ports equal (or bigger) to the number of VICAMATIC-2 units included in the network. LAN hubs are not included

Spare Parts

UTCM-0560 1,13 mm dia. needle for initial setting time test to EN
UTCM-0561 1 mm dia. needle for setting time test to ASTM/AASHTO
UTCM-0562 Plastic mould to EN
UTCM-0563 Plastic mould to ASTM/AASHTO
UTCM-0564 Glass base plate
UTCM-0565 Spare base plate for in-water testing kit

UTCM-0550E is supplied complete with EN 196-3 accessories: initial setting time needle 1.13 mm dia., mould and PC software VICASOFT-BASIC.

‍

Why the GS9000 matters for SUE businesses

Increase area covered per field day
Reduce the number of manually positioned survey lines
Improve coverage in congested corridors
Review coverage before leaving site
Produce higher-value mapped deliverables
Combine GPR and GNSS in one workflow
Retain raw data for later reinterpretation
Expand from locating into mapping and subsurface modelling

‍

Book a SUE Workflow Demonstration

‍

High-resolution multichannel GPR for structures, bridges and pavements

The GX1 transforms the GS9000 into a high-resolution structural assessment system for concrete slabs, bridge decks and pavements. Its dense, dual-polarisation array captures detailed 3D data across wide areas, supporting reinforcement and cover mapping, moisture and deterioration assessment, and analysis of asphalt and pavement layers. Live visualisation helps confirm survey coverage on site, while post-processing tools produce clear, report-ready condition maps.

Bridge-deck reinforcement and condition mapping
Concrete-cover mapping
Reinforcement layout and spacing
Moisture-related and deterioration mapping
Asphalt and pavement-layer thickness
Road and runway investigations
Detection of embedded features
Large-area concrete-slab investigations
Comparative and repeat surveys

‍

The structural assessment workflow

1. Define the inspection area

Import the structure, bridge, pavement or survey background.

2. Collect closely spaced profiles

Capture 35 longitudinal and 15 cross-polarised channels with dense spacing.

3. Review coverage in the field

Use live radargrams and time slices to confirm that the required area has been captured.

4. Process the dataset

Apply velocity, gain, background removal, migration, filtering and topographic correction as appropriate.

5. Generate diagnostic maps

Create depth slices, reinforcement maps, layer information or application-specific condition maps.

6. Integrate with the engineering assessment

Export figures, mapped anomalies and raw data for inclusion in the engineer’s final interpretation and report.

‍

Structural outputs and engineering value

Field information

Processed Diagnostic Information

Engineering deliverables

‍

When to use the GS9000 rather than a handheld GPR

Use a handheld or single-channel GPR when…

Use the GS9000 when…

The inspection area is small
You need local marking before drilling
Rapid spot checks are sufficient
Manoeuvrability is the main priority
The output is primarily site marking

Large areas must be covered
A completely mapped dataset is required
Large datasets are required
Productivity and spatial continuity are priorities
The output must support reporting or engineering interpretation

Book a Structural Assessment Demonstration

‍

One GS9000 platform

Onboard instantaneously mapped results
Interchangeable array modules
Foldable carbon-fibre cart
Rear-wheel encoders
Hot-swappable power banks
Wireless iPad operation
IP65 protection
Integrated GNSS
Approximately 1–5 cm real-time GNSS accuracy where suitable corrections and conditions are available
Free-path and structured survey methodologies

‍

Field software, post-processing and Workspace

Field App

Workspace

GPR Insights post-processing

Live radargrams and time slices
Satellite, GNSS and CAD overlays
Tags, photographs, voice markers and linework
Field calibration and processing
Immediate review of survey coverage

Synchronise projects
Store and share data
Collaborate remotely
Run connected GNSS and conversion services
Share projects through a URL

Merge multiple field projects
Advanced 2D and 3D visualisation
Filtering and migration
Topographic correction
Application-specific mapping tools

‍

Configurations and what is included

GS9000 cart with:

GX1 and/or GX2 array option
MA8000 GNSS receiver and correction options
Latest version of GS App with live updates
Advanced GPR Insights processing software access
Cloud storage on Workspace
Batteries and chargers
Training
Commissioning
Kit with all required cables and tools

‍

‍

Why purchase from PCTE

Australian and New Zealand application advice
Local demonstrations
Configuration selection
On-site commissioning
Operator training
Data interpretation and workflow training
Local technical support
Service and repair coordination
Assistance with GNSS, coordinate systems and deliverables
Access to related GPR and structural NDT equipment

‍
